Multi Core Fiber Fan Outs
Plug-and-play component for multicore fibers
- Compact package size
- High data rates
- Scalable manufacturing technique
Typical Applications:
- 2D bend sensing
- Active Optical Cables (AOCs)
- Photonic Integrated Circuits
- Distributed sensing
Comparison
| Model | FAN-4C | FAN-7C |
|---|---|---|
| Operating Wavelength (nm) | 1550 | 1310 & 1550 |
| Insertion Loss (dB) | 1 (typical) |
1310: 1-2 (typical) 1550: 1 (typical) |
| Number of Cores | 4 | 7 |
| Crosstalk (dB) | ≤-45 (typical) | ≤-45 (typical) |
| Core Configuration | Square |
1310: Hexagon plus central core 1550: Spun Hexagonal plus central core |
| Operating Temperature (°C) | 0 to +85 | 0 to +85 |
| Connectorization |
Single core: None, LC/PC, LC/APC, FC/PC, FC/UPC, SC/PC, SC/APC, MTP/APC and others upon request Multicore: None, FC (narrow keyway), SC (all in PC or APC) and others upon request |
Single core: None, LC/PC, LC/APC, FC/PC, FC/UPC, SC/PC, SC/APC, MTP/APC and others upon request Multicore: None, FC (narrow keyway), SC (all in PC or APC) and others upon request |
Specifications
Product Variants Explained
|
FAN-4C |
Fan-out unit designed to guide light from a 4 core fiber into 4 separate SMF28 pigtails. |
|
FAN-7C |
Fan-out unit designed to guide light from a 7 core fiber into 7 separate SMF28 pigtails. |
Product Specifications
| Operating Wavelength (nm) | 1550 |
|---|---|
| Insertion Loss (dB) | 1 (typical) |
| Number of Cores | 4 |
| Crosstalk (dB) | ≤-45 (typical) |
| Core Configuration | Square |
| Operating Temperature (°C) | 0 to +85 |
| Connectorization | Single core: None, LC/PC, LC/APC, FC/PC, FC/UPC, SC/PC, SC/APC, MTP/APC and others upon request Multicore: None, FC (narrow keyway), SC (all in PC or APC) and others upon request |
Resources
Technical Bulletins
File
md47.8-fan-outs.pdf
