Ruggedized Fiber Cable

Protects Valuable Fiber

  • Options available from 900μm tight or loose buffer to 3mm aramid reinforced  cable
  • Available in blue (for PM fibers) and yellow (for non-PM fibers), orange (MM fiber) and yellow (for other fiber), or other colors by request
  • Provide essential protection in indoor and outdoor applications
  • Fully compatible with the Fibercore range of connectors

Enables rapid fabrication of short custom cables

  • Furcation cable option
  • Available without the fiber or connectors
  • Nylon pull-cord allows ruggedization of virtually any fiber

Typical applications:

  • Sensor cables
  • Medical probes
  • Beam delivery

    Comparison
    Model 900µm Hytrel® LT3(0.5/0.9) LT3(1.0/1.8)
    Sheath Outer Coating (mm) 0.9 2.8 2.8
    Sheath Material Hytrel® PVC (blue) PVC (blue)
    Loose Tube Outer Diameter (mm) - 0.9 1.8
    Loose Tube Inner Diameter (mm) - 0.5 1.0
    Loose Tube Material - Hytrel® (with fiber) Hytrel® (with fiber)
    Reinforcement - Aramid Yarn Aramid Yarn
    Pull Cord No Yes (Nylon filament) Yes (Nylon filament)
    Product Variants Explained
    • 900µm Hytrel® sleeving
    Sheath Outer Coating (mm) 0.9
    Sheath Material Hytrel®
    Loose Tube Outer Diameter (mm) -
    Loose Tube Inner Diameter (mm) -
    Loose Tube Material -
    Reinforcement -
    Pull Cord No
